SPECIFICATIONS

Application: HVAC, industrial

Frame: Plastic

Spacers: -

Bonding: 2 component polyurethane

Media: Synthetic - PS

Gasket: Continuous poured gasket

Filter class according to EN779:2012: G4

Maximum/recommended final pressure drop: 250Pa

Maximum temperature: 70°C

Maximum relative humidity: 90%

Comments: Very good alternative for the APMC filter


ADVANTAGES

• Very low pressure drop

• Firm construction

• Totally combustible

• No corrosion


DETAIL


Advantages of panel filters

• Large filter surface

• High particle interception capacity

• Lengthy service life

• Low energy consumption

• Dimensions compliant with EN15805

• Moisture-resistant cardboard frame

• Completely safe for incineration


Construction

Panel filters are pleated filters which are assembled within a moisture-resistant cardboard

frame.


Application

Panel filters are used as a pre-filter for air treatment cabinets, air conditioning systems

and industrial systems.


Installation

• Ensure that the filter is fitted correctly:Suction side – clean air side

• Filter should be correctly installed: no leaks

• Gaskets should be completely undamaged

• Filter should be secured at four points

• Ensure that the filter medium is not folded double

• Take care to avoid damaging the filter during installation

• System should be run in for several hours to achieve the desired result

• Filter installation records; note the date, type and initial resistance.
